Site Settings

Site Settings allows you to view and configure site-wide options. Click the action button and select Site Settings.

General

FIELD DESCRIPTION
Administration help URL Change the URL of WebMap Manager Help to point to your own help page.
User help URL Change the URL of WebMap User Help to point to your own help page.
Google Site Tag Enable support for Google Analytics. Simply add the relevant tag here. Remember this works best on publicly accessible WebMap sites. Related Topics Link IconRelated Topics
Cookie Consent Enable consent dialogue window to allow cookies Related Topics Link IconRelated Topics
Default Base Layer Opacity Default Opacity to apply to any new base layers that maybe created.
Allow Switching ofMaps Enable to allow user to switch between two or more maps.

Theme

FIELD DESCRIPTION
Accent Colour used as an ‘accessory’. These are usually bright shades to engage attention (can be used for links, highlights etc)
Error Colour used for error messages
Primary Colour used most frequently across a website's screens and components (e.g. toolbars and buttons)
Secondary Colour used with the primary shade to provide contrast.
Use Dark Text Enable to use dark text if the colour theme is lighter.

CORS

Cross-Origin Resource Sharing (CORS) uses additional HTTP headers for specific sharing purposes. Enable or disable accordingly.

FIELD DESCRIPTION
Allow All CORS Enable to give access to resource sharing
Don't Allow CORS Enable to deny access to resource sharing
Allow Custom CORS Enable to allow custom headers or domains or a combination of both.
Domains Specifies the domains allowed during the actual request. These are separated by commas. For e.g., http://domain1.example, http://domain2.example
Headers Specifies the HTTP headers allowed during the actual request. Click here for the header syntax.
Methods Specifies the method(s) allowed when accessing the resource (GET, POST etc). Click here for syntax

Note: For more on CORS, see our GeognoSIS help

Mail

Select the mail type to be used.

FIELD DESCRIPTION
SMTP Specify the Host, Port and Secure Socket Options
GraphAPI Uses Microsoft Graph API. Changes are made to Azure to enable WebMap 9.1 to send mail. Graph API requires Client (Application) and Tenant IDs, Client Secret and an account whose mailbox will be used.

Headers

Custom headers can be added to enable using WebMap from a client in a different domain- this is mainly used for heightened security.

See here for examples of custom headers.

Rate Limiter

On Public Maps, user traffic and requests can trigger a web page crash. On rare occasions, heavy usage may even originate from malicious sources resulting in a Denial-of-Service (DoS) attack. This can shut down a machine or network, making it inaccessible to users.

To regulate traffic and prevent attacks, enable Rate Limiter options.

FIELD DESCRIPTION
Maximum request rate per time window The maximum number of successful requests allowed within the specified period or time window.
Maximum queue rate per time window The maximum number of queued requests allowed within the specified period or time window.
Time Window Specific time frame (in seconds) within which a maximum number of requests can be made.
